Dräger PAS® Lite Self Contained Breathing Apparatus (6L/300 Bar)

For use in industrial applications where a simple, robust and easy to use breathing apparatus is required, the Dräger PAS® Lite Self-Contained Breathing Apparatus (SCBA) combines reliability with comfort and performance, as well as excellent service life and easy maintenance.

– Inculdes Dräger Panaroma Face Mask and Compressed Air Pressure Cylinder 6L
– Air Pressure Cylinder comes in 300 bar (Composite) or 200 bar (Steel)


We provide recharging of air cylinder. Contact Us to find out more.

Contact Us Now to Purchase This Product and Enhance Your Safety!

Get in touch now by clicking the WhatsApp button below!

Other ways to get in touch with us:

enquiry@tecs-firensafety.com.sg

+65 6362 1886

Share:

Dräger PAS Lite – A

Technical specifications
Weight
2.7 kgs
Dimensions
590 x 290 x 160 mm
Input Pressure
0 – 300 bar
Nominal 1st stage output pressure
7.5
1st stage output flow
> 1000 l/min
LDV output flow
> 400 l/min
Whistle Sound Level
> 90 dBA
Approvals
EN 137 2006 Type 2, EN 14593 pt1 (for PAS ASV), MED, SOLAS II-2, can be used in hazardous areas.

Advanced technology

With a proven design and using the same high quality pneumatics as found in professional firefighter breathing apparatus, the Dräger PAS Lite ensures consistent high performance and reliability over the lifetime of the apparatus with minimal maintenance. The carrying system features an ultra lightweight, high strength carbon composite space-frame having excellent impact, heat and chemical resistance, as well as outstanding durability.

Integrated hose design

Both the air supply and gauge hoses are mounted into the space-frame, thus reducing the risk of snagging and entanglement. This enables the user to change the hose position from one side to another to suit individual preference. The fully integrated hose design also means that hoses can be replaced easily and cost effectively.

Efficent load distribution

Incorporating new materials that are shaped and formed to provide maximum comfort at both the shoulders and the waist, the carrying system has been developed to reduce back strain, stress and fatigue. The innovative harness design ensures an excellent weight distribution at the shoulders. The inclusion of durable rubber coated fabric provides excellent wearing comfort and chemical resistance, whilst also performing well during flame engulfment tests in line with EN137 Type 2.

Service friendly

A number of unique design features ensure that downtime and costs are kept to a minimum during repair and maintenance. All major components of the SCBA Dräger PAS Lite are quick and easy to assemble and disassemble, including the harness which is attached to the space-frame by a simple single-piece retention method. The reducer is contained in the space-frame for added protection and can easily be removed with simple tools.

Proven, robust and flexible

In line with other Dräger breathing apparatus, the Dräger PAS Lite allows users to take advantage of the tried and tested systems that lie behind the best breathing apparatus in the world. Developed as a result of years of research and extensive user consultation, these benefits include the use of the same advanced pneumatics as used in the whole professional firefighting range of Dräger.

The Dräger PAS Lite can be further adapted to suit specific industrial applications. As well as standard fit easy to clean harness, integrated Lung Demand Valve (LDV) or airline ready options such as the Dräger PAS ASV can be specified. Integrating easily with all Dräger PAS Airline equipment, this flexible breathing apparatus is also fully compatible with Dräger Panorama® Nova and FPS® 7000 full face mask ranges.

A minimum of 5 sets of this PPE are required, for 1 SIC and 4 ERT members.

SCDF NATIONAL CERT STANDARD
